Where you have applied OOPS in Automation Framework
You may face this question (Where you have applied OOPS Concept in Automation Framework) in almost all the Selenium Interviews. Learn OOPS concept in Java before going further. Earlier we have posted OOPS concept in Java with some easy to understand examples.
Also check this post on explanation of Selenium automation framework. I use components of this post to explain the current post (i.e., application of OOPS concepts in Automation Framework).
Concepts of OOPS in Selenium Automation Framework
In this post, we will discuss how and where we applied following OOPs concepts in an Automation Framework.
Abstraction is the methodology of hiding the implementation of internal details and showing the functionality to the users.
Let’s see an example of data abstraction in Selenium Automation Framework.
In Page Object Model design pattern, we write locators (such as id, name, xpath etc.,) and the methods in a Page Class. We utilize these locators in tests but we can’t see the implementation of the methods. Literally we hide the implementations of the locators from the tests.
Learn more on Abstraction
In Java, abstraction is achieved by interfaces and abstract classes. Using interfaces, we can achieve 100% abstraction.
Let’s see interface concept below.
Basic statement we all know in Selenium is WebDriver driver = new FirefoxDriver();
Detailed explanation on why we write WebDriver driver = new FirefoxDriver(); in Selenium.
WebDriver itself is an Interface. So based on the above statement WebDriver driver = new FirefoxDriver(); we are initializing Firefox browser using Selenium WebDriver. It means we are creating a reference variable (driver) of the interface (WebDriver) and creating an Object. Here WebDriver is an Interface as mentioned earlier and FirefoxDriver is a class.
An interface in Java looks similar to a class but both the interface and class are two different concepts. An interface can have methods and variables just like the class but the methods declared in interface are by default abstract. We can achieve 100% abstraction and multiple inheritance in Java with Interface.
Learn more on Interface here.
The mechanism in Java by which one class acquires the properties (instance variables) and functionalities of another class is known as Inheritance.
We create a Base Class in the Automation Framework to initialize WebDriver interface, WebDriver waits, Property files, Excels, etc., in the Base Class.
We extend the Base Class in other classes such as Tests and Utility Class.
Here we extend one class (Base Class like WebDriver Interface) into other class (like Tests, Utility Class) is known as Inheritance.
Learn more on Inheritance here.
Polymorphism allows us to perform a task in multiple ways.
Combination of overloading and overriding is known as Polymorphism. We will see both overloading and overriding below.
Learn more on Polymorphism here.
#1. METHOD OVERLOADING
We use Implicit wait in Selenium. Implicit wait is an example of overloading. In Implicit wait we use different time stamps such as SECONDS, MINUTES, HOURS etc.,
Action class in TestNG is also an example of overloading.
Assert class in TestNG is also an example of overloading.
A class having multiple methods with same name but different parameters is called Method Overloading
Learn more on Overloading here.
#2. METHOD OVERRIDING
We use a method which was already implemented in another class by changing its parameters. To understand this you need to understand Overriding in Java.
Declaring a method in child class which is already present in the parent class is called Method Overriding. Examples are get and navigate methods of different drivers in Selenium .
Learn more on Overriding with examples here
All the classes in a framework are an example of Encapsulation. In POM classes, we declare the data members using @FindBy and initialization of data members will be done using Constructor to utilize those in methods.
Encapsulation is a mechanism of binding code and data (variables) together in a single unit.
Learn more on Encapsulation here
Other Selenium Automation Framework Concepts
I would like to discuss some other topics which we use in Automation Framework.
#1. WEB ELEMENT
Web element is an interface used to identify the elements in a web page.
WebDriver is an interface used to launch different browsers such as Firefox, Chrome, Internet Explorer, Safari etc.,
#3. FIND BY
FindBy is an annotation used in Page Object Model design pattern to identify the elements.
#4. FIND ELEMENT
Find Element is a method in POM to identify the elements in a web page.
Learn Java – A customized post for Selenium Automation Testers
